Adding a 4th axis to micromill

Posted: Wed 18 Sep , 2019 14:40 pm
by MadeForThat
I have already initiated this project, but figured I would document what I have done thus far with some pics. I was able to snag a sherline rotary table off of ebay for a pretty good deal. It had a stepper and an encoder on it, but i opted not to keep the encoder, as it has its own set of difficulties. I replaced it with a thumb wheel that I turned and knurled at work. The next problem was mounting the table on to my mill's bed. I made up some T nuts at work, (just buy T nuts lol) and drilled in some new mounting holes. After shortening some 10/32 bolts, the table mounted firmly on to the bed :) As for controlling the stepper, I had picked up some random electronics from a gentleman at a garage sale. Among this "junk" was a stepper driver that coincidentally uses the same L2**** chip that the control board uses. I mounted that under the spindle controller. I have not tested the two together, but that is coming soon :) In order to control the stepper driver, I will be swapping in a nextstep card for my micromill's Denstep. The reason for this: the nextstep card has 4 step/dir outputs where the denstep only has 3. The Nextstep card is from my lathe anyways, so I'm not loosing any function by downgrading it to a denstep card. (I think/hope) On the Nextep card, there is a header with access to all step /direction output. See: viewtopic.php?f=54&t=3576 This will be easy to make a suitable connector, and I can run that directly to my step driver.

Re: Adding a 4th axis to micromill

Posted: Thu 19 Sep , 2019 14:51 pm
by MadeForThat
So if you were thinking that this seems to easy--> you were right... I was able to get the mill jogging with the nextstep card, and i was getting pretty excited that it was going to be easier than I thought. When I went to enable the 4th axis, I was unsurprisingly hit with the error pictured below. It does not seem that any of the micromill profiles have the 4th axis as an option. (I am assuming the "micromill" is the successor/NS to the micromill2000) I think this means I will need to modify one of the profiles that does, and change the machine parameters to match my hardware. Not super excited to learn about mint, but I'll take any opportunity to learn a new skill. I have not started reading up on this, so if any cnc guru's have recommendations for reading, I would be very appreciative.

Re: Adding a 4th axis to micromill

Posted: Thu 19 Sep , 2019 18:26 pm
by TDIPower
The guys at denford will know best BUT I wonder if you could use a Novamill or microrouter with 4th axis and just rejig the settings within those files to those of the micromill eg speeds and sizes.

Pete

Re: Adding a 4th axis to micromill

Posted: Thu 19 Sep , 2019 21:09 pm
by MadeForThat
Yeah, i was actually wondering if there were more settings than what are accessible to change under machine parameters? If not I think i can just take some pictures of the micromill parameter pages, edit the novamill to match, and then select novamill as the device. No need to even open a .mex. That would be pretty slick

Re: Adding a 4th axis to micromill

Posted: Thu 19 Sep , 2019 22:14 pm
by TDIPower
when I was testing the NS board I have to upgrade my Lathe, I just dropped it straight into my Mircorouter, VR did it's erasing flash thing on connection at it worked straight off for the microrouter. so the board just works on what it's told to do, obviously I didn't try rewriting anything for this it was just to check functionality.

I very much doubt you will hurt anything just swapping the settings and giving it ago, Just looked on VR the IV axis has a few options A,B,C (1,2 or 3). Not sure what that would be for though or where a home switch if fitted could be wired to.

Re: Adding a 4th axis to micromill

Posted: Mon 23 Sep , 2019 14:47 pm
by MadeForThat
Everything seems to work great! I will be wiring in everything this week, and i will be able to do some testing next weekend!

Re: Adding a 4th axis to micromill

Posted: Mon 23 Sep , 2019 17:04 pm
by TDIPower
great stuff!!!

Re: Adding a 4th axis to micromill

Posted: Thu 26 Sep , 2019 18:10 pm
by MadeForThat
Well I always seem to think things will just fall into place. Here is another minor detail I need to sort. my stepper driver is for a 4 wire bipolar motor. I have an 8 wire stepper, wired into 5 wires with a ground for a total of 6 wires in the cable. This is a cool opportunity to learn about bipolar series and bipolar parallel, and I have yet to decide on which I plan to rewire the stepper to match. NOTE: this is not a denford sourced motor, and is likely from a Taig or MAXNC mill, based on the table mount holes that were on it. (These 2 companies used sherline rotary tables, but would retrofit their own controls, hence the odd stepper config.) This section of this post is probably not applicable to most. below are some pics that I am using to map my wires haha

Re: Adding a 4th axis to micromill

Posted: Fri 27 Sep , 2019 18:43 pm
by TDIPower
really loving this work. I've never used 4th axis and can't wait to see this in action, I will be bouncing you the questions if i decide to do something like this in the future!

Pete

Re: Adding a 4th axis to micromill

Posted: Sat 28 Sep , 2019 7:29 am
by MadeForThat
We have motion!! Tonight I got it all wired up and turning! It seems to struggle with torque, so I am starting to regret wiring my stepper in bipolar series (lower power consumption and torque) I plan to try hooking in a new power supply for that drive, as I would like to make sure it is maxed out on available power before I go back and redo my connections. Not sure if the vid will post below, hopefully

Re: Adding a 4th axis to micromill

Posted: Tue 01 Oct , 2019 23:03 pm
by MadeForThat
More power did the trick! I used a laptop power supply, giving 19.5v at 4 amp. Much more than required, but within the range that both the motor and the controller could function. Wiring in the new supply was easy, I ended up just running it in parallel with the ac transformer, as this is controlled by the main power relay and has a fuse. (hopefully I don't blow fuses under load, but I wont know until I do) There is a part of me who is disappointed that I did not run a new fuse and linked it in a uniform way, but unfortunately that part was outweighed by the rest of me who wanted to get it all running. Amazon has a lot of "DIN fuse holders" so if I do blow a fuse, I will be taking the time to run a separated line. I will start programming a little something this week, and will try to get a video uploaded.
